Matsuura MX-330 5-Axis VMC 2015, with: G-Tech 31i CNC Control, High Pressure Coolant, Laser Tool Probe, and Chip Conveyor.

Inventory

Matsuura MX-330 5-Axis VMC 2016, with: Fanuc 31i CNC Control, 60 Tool ATC, Spiral Chip Augers, CAT 40 Big Plus, Coolant Through Spindle, LNS Chip Conveyor.

BrandMATSUURA

ModelMX-330

TypeMachining Centers, Vertical, (5-Axis or More)

Stock #6368

ConditionNot specified

Year2018

LocationCity Not Specified, State Not Specified
United States

Request a Quote

Matsuura MX-330 5-Axis VMC 2016, with: Fanuc 31i CNC Control, 60 Tool ATC, Spiral Chip Augers, CAT 40 Big Plus, Coolant Through Spindle, LNS Chip Conveyor.

Specifications
Files & Attachments

CNC Control	yes
Type of CNC Control	Fanuc 31i
Table Working Surface	11.81 inches
Max Table Load	440 pounds
# Axis	5
X	24.8 inches
Y	22.04 inches
Z	20.07 inches
A-Axis Trunnion Tilt Range	-125~+10 Degrees
C-Axis Table Rotation Positioning Degrees	360
RPM	15000
Power	11 horsepower
# ATC	60
Taper	CAT 40 Big Plus

Fanuc 31i CNC Control, 60 Tool ATC, Spiral Chip Augers, CAT 40 Big Plus, 250mm Table, Coolant Shower, EZ 5 Calibration Software w/o Calibration Ball, OMP 60-2 OTS Dual Probe Kit w/OMP60 IPM Probe & OTS, ATS/Cooljet T8-300 PSI Coolant Through Spindle, Vacuum Type CTS Prep, Scale Feedback-X,Y,Z, MMU High Speed Precision and 5-Axis Option Package, MMU Value Option Package with No. of Registered Programs (1000pcs), CAMplete Posting and Verification Software, 15,000 RPM Maxia Power-Up Spindle, and LNS Turbo SF Compace Chip Conveyor.

Matsuura MX-330 5-Axis VMC 2016, with: Fanuc 31i CNC Control, 60 Tool ATC, Spiral Chip Augers, CAT 40 Big Plus, Coolant Through Spindle, LNS Chip Conveyor.
