BrandHAAS
ModelVF-6/40
Stock #6606
ConditionNot specified
Year2022
LocationFullerton, California
United States
| X-Axis Travel | 64.0 inches |
| Y-Axis Travel | 32.0 inches |
| Z-Axis Travel | 30.0 inches |
| Spindle Nose to Table (~MAX) | 34.0 in |
| Spindle Nose to Table (~MIN) | 4.0 in |
| Spindle Max Rating | 30.0 hp |
| Spindle Max. Speed | 10,000 rpm |
| Spindle Max Torque | 90.0 ft-lbf @ 2000 rpm |
| Max Torque w/opt Gearbox | 250 ft-lbf @ 450 rpm |
| Spindle Drive System | Inline Direct-Drive |
| Spindle Taper | CT40 |
| Spindle Bearing Lubrication | Air / Oil Injection |
| Spindle Cooling | Liquid Cooled |
| Table Size (LxW) | 64.0 in x 28.0 in |
| T-Slot Width | 0.626 in to 0.630 in |
| T-Slot Center Distance | 4.92 in |
| Number of Std T-Slots | 5 |
| Max Weight on Table (Evenly Distributed) | 4000 pounds |
| Max Cutting | 500 ipm |
| Feedrates: Rapids on X-Axis | 600 ipm |
| Feedrates: Rapids on Y-Axis | 600 ipm |
| Feedrates: Rapids on Z-Axis | 600 ipm |
| Axis Motor Max Thrust X | 3400 lbf |
| Axis Motor Max Thrust Y | 3400 lbf |
| Axis Motor Max Thrust Z | 5600 lbf |
| Tool Changer Type | SMTC |
| Tool Changer Capacity | 30 |
| Dimensions (LxWxH) | 157 in x 96 in x 100 in |
| Weight | 22300 pounds |
10,000 RPM Spindle, Remote Hand Jog, Programable Coolant, Chip Auger, Chip Strainer, ** BANK OWNED OPEN TO ALL OFFERS**
Short Terms and Conditions of Sale (Please contact us for complete Terms and Conditions): Unless otherwise posted, all items are sold AS-IS, WHERE-IS With All Faults. All specifications must be independently verified, and locations are subject to change without notice. All items are subject to availability and prior sale.
